be quiet! Shadow Base 800 FX White
Vorige
be quiet! Shadow Base 800
Op voorraad bij leverancier (2-5 werkdagen)
Shadow Base 800 is an airflow-optimized full-tower that offers silent operation with enough space for extensive components such as graphics cards, 420mm radiators or E-ATX motherboards.
Exceptionally high airflow thanks to an open mesh design
3 Pure Wings 3 140mm PWM fans offer high airflow with quiet operation
Spacious design offers enough room for even the largest components
Simple and tool-less HDD and SSD installation
Rotatable PCIe slots enable vertical installation of GPUs
Easy to use cable bar for a neat and tidy look
Tinted and tempered glass side window allows a superb view
3-year manufacturer’s warranty
General data
Model Shadow Base 800
Color option Black
Motherboard compatibility E-ATX / ATX / M-ATX / Mini-ITX
Case size excl. stands (L x W x H), (mm) 550 x 247 x 503
Case size incl. stands (L x W x H), (mm) 550 x 247 x 522
Volume (l) 62.74
PSU form factor ATX PS/2
Weight (kg) 11.7
Expansion slots 7
Pre-installed fans
Fan at top 1x Pure Wings 3 140mm PWM
Fan at front 1x Pure Wings 3 140mm PWM
Fan at side -
Fan at rear 1x Pure Wings 3 140mm PWM
Fan at bottom -
Dimensions (L x W x H), (mm) Front: 140 x 140 x 25 / Rear: 140 x 140 x 25 / Top: 140 x 140 x 25
Fan speed at 100% PWM / 12V (rpm) 1200
Airflow at 100% PWM / 12V (CFM / m3/h) 57.4 / 97.5
Air Pressure at 100% PWM / 12V (mm H2O) 0.96
Noise level at 100% PWM / 12V (dB(A)) 21.9
Voltage range (V DC) 5 - 13.2
Input power (W) 3.6
Input current (A) 0.3
Connector 4-pin PWM
Lifespan (h / 25°C) 80,000
Fan controller -
Maximum fan installation
Maximum fans 8
Top (mm) 3x 140 / 3x 120
Front (mm) 3x 140 / 3x 120
Side (mm) -
Rear (mm) 1x 140 / 1x 120
Bottom (mm) 1x 140 / 1x 120
PSU shroud -
Optional radiator installation
Top (mm) 120 / 140 / 240 / 280 / 360 / 420
Front (mm) 120 / 140 / 240 / 280 / 360 / 420
Side (mm) -
Rear (mm) 120
Bottom (mm) -
PSU compatibility
Maximum dimensions excl. bottom fan (mm) 305
Maximum dimensions incl. bottom fan (mm) 260
Graphics card
HDD cage (in height of graphics card) installed (mm) 430
HDD cage (in height of graphics card) removed (mm) 430
Maximum PCIe slots with vertical graphics card (pcs.) 7
Drive bay capacity
5.25 bays (pcs.) -
3.5 slots (scope of delivery) 2
3.5 slots (max.) 4
2.5 slots (scope of delivery) 4
2.5 slots (max.) 8
Cooling
Max.construction height of CPU cooler unit (mm) 180
Airflow channel Front / Top / Rear / Bottom
Lighting
LED illumination -
LEDs (pcs.) -
LED type -
LEDs synchronizable with controller/motherboard -
I/O Panel
USB 3.2 Gen. 2 Type C 1
USB 3.2 Type A 2
USB 2.0 -
HD Audio I/O Mic + Audio
Qi charger / Quick Charging Option -
Insulation and damping
Top panel insulation mats -
Front panel insulation mats -
Side panel insulation mats ✓
Anti-vibration decoupled HDD ✓
Anti-vibration decoupled fan ✓
Anti-vibration decoupled PSU ✓
Anti-vibration decoupled motherboard-tray -
Removeable dust filters
Top -
Front 1
Side -
Bottom 1
Material
Top cover ABS
Front panel ABS
Side panel Steel
Side panel window 4mm Tempered Glass
Stands ABS
Safety certification
Approvals CE, UKCA
Environmental directives
RoHS ✓
Reach ✓
WEEE ✓
Triman ✓
Scope of delivery
Screw set (Drives/Motherboard) ✓
Additional standoffs (pcs.) -
SSD bracket for PSU shroud -
LED strips (pcs.) -
Cable ties (pcs.) 6 (Velcro) / 4 (Velcro)
Screw box -
VGA holder -
VGA holder for inverted layout -
Mesh Front Panel -
ODD Bracket -
Fan / Radiator bracket for multi mounting panel -
Service
Warranty (Years) 3
International hotline / free of charge ✓ / DE, FR
| EAN | 4260052190609 |
|---|---|
| Vendor ID | BGW60 |
| Soort kast | Midi tower |
| Materiaal | Staal / Glas |
| Aantal 3,5 inch intern | 2 bays |
| Aantal 2,5 inch intern | 4 bays |
| Aantal 5,25 inch extern | Nee |
| Venster in de zijkant | Ja |
| Front USB aansluiting | USB 3.0 / USB 3.1 |
| Form Factor | EATX |
| Inclusief voeding | Nee |
| Color | Zwart |
