be quiet! Shadow Wings SW1 120mm High-Speed

€16,00
End of life
SKU
TL9V3B
Vragen over dit product ? Of wenst u meer info... - Bel ons 014610096 !
Twijfelt u over compatibiliteit, gelieve ons even te contacteren, we helpen u graag verder !

    Very quiet operation

  • Low-noise operation due to high-quality rifle bearing. The parallel arrangement of recesses on the outer side of the bearing shaft ensure uniform circulation of the high-quality oil and make the fan very quiet. Mechanical noise is minimized by antivibration fasteners and the rubberized fan frame. The high-quality IC motor controller reduces electrical noise sources.



    Long service life

  • Reliable cooling for up to 200,000 hours thanks to the high-quality rifle bearing.



    High air flow

  • The flow-optimized surface structure of the fan blades produce more air flow in combination with smooth running.



    Simple assembly

  • Screwless installation makes handling simple.



    Service

  • 3 year manufacturer guarantee.

General

Model
SHADOW WINGS SW1 120mm 2200rpm

General Specs

Dimensions (L x W x D), (mm)
120 x 120 x 25
Fan speed @ 12V (rpm)
2200
Air flow @ 12V (cfm, m3/h)
76.2 / 129.1
Air pressure @ 12V (mm H2O)
2.70
Noise level @ 12V (dB(A))
29.7

Mechanical spec

Dimensions (L x W x D), (mm)
120 x 120 x 25
Bearing type
Rifle
Weight incl. fixed cables (kg)
0.22
Push pin fixing
Screw fixing
-

Cables & Connectors

Connector
3 pin
Cable length (mm)
450
Cable sleeve
-

Performance & Noise

Fan speed @ 12V (rpm)
2200
Air flow @ 12V (cfm, m3/h)
76.2 / 129.1
Air pressure @ 12V (mm H2O)
2.70
Noise level @ 12V (dB(A))
29.7
Lifespan (h / 25°C)
200.000

Electrical specs

Rated voltage DC (V)
12
Starting voltage DC (V)
5
Operating voltage DC (V)
5 ~ 12
Current consumption (A)
0.28
Safety current (A)
0.45
Input power (W)
5.40

Accessories

3pin to 4pin Y-connector
-
12V to 7V adapter
12V to 5V adapter
-
Screws
-
Push pins
5
Silica gel washer
5
Others
-

Safety certification

Approvals
CE, RoHS, WEEE, RU, Tüv

Service

Warranty (Years)
3
International hotline / free of charge
✓ / DE, FR

Logistics data, RRP

Range
SHADOW WINGS
Article number
BL055
EAN Code
4260052182734
Meer informatie
EAN 4260052182734
Vendor ID BL055
Voorraad status End of life
Verlichting Geen
Afmeting 120 mm
CFM ( Airflow ) > 60 CFM
Fan Decibel MAX < 30 dB
Toeren/minuut > 1600 rpm
Fan controller Nee
