Be quiet! Silent Loop 360mm

€181,00
End of life
SKU
HXLVBJ
Vragen over dit product ? Of wenst u meer info... - Bel ons 014610096 !
Twijfelt u over compatibiliteit, gelieve ons even te contacteren, we helpen u graag verder !

Superior Cooling and Silence

With Silent Loop be quiet! brings whisper-silent technology to the world of All-in-One watercooling, making liquid cooling an attractive option for those who want to heavily overclock CPUs for maximum processing performance or cool high-power PC systems.

  • All-in-One water cooling provides everything you need in one package
  • Innovative decoupled reverse-flow pump assures excellent cooling efficiency with whisper-quiet operation
  • Three Pure Wings 2 120mm PWM fans feature airflow-optimized fan blades and variable speed operation
  • Full copper radiator maximizes heat transfer for peak cooling performance
  • Refill port and flexible bend-protection tubes extend the product’s life span and promote easy handling
  • Compatible with Intel® and AMDTM sockets, and sized to permit full use of RAM slots
  • Product conception, design and quality control in Germany

Applications

  • Demanding PC systems
  • Heavily overclocked systems
  • High-resolution gaming and multimedia systems
  • Any PC that requires superior quietness, such as audio editing, studio work, or simply a HTPC

Feature Details

Ultra-quiet Operation

  • Innovative decoupled reverse-flow pump provides low-noise operation with less vibration
  • Thanks to the technique “reverse-flow” the pump draws the liquid coolant from an outer cavity of the pump housing across the base plate and discharges the warmed liquid coolant through a second level inside
  • Three Pure Wings 2 120mm PWM fans include an array of optimizations for quiet airflow
    • unique airflow-optimized fan blade design reduces noise-generating fan turbulence
    • high-quality rifle bearing technology contributes to a long lifespan of up to 80,000 hours
    • PWM speed control function allows for optimum balance between quiet operations and efficient cooling

Superior Cooling Performance

  • Full copper radiator maximizes heat transfer for peak cooling performance
  • Nickel-plated coldplate allows the use of heat-conducting metallic paste, thus improving heat transfer and overall cooling efficiency
  • Extremely high TDP rating supports heavily overclocked CPUs and demanding systems
  • Increased air pressure thanks to a highly efficient blade design of the three 120mm Pure Wings 2 PWM fans, making these fans the perfect partners to work with the radiator

Maximum Compatibility and Convenience

  • Flexible bend- and pinch-protected tubes take the worry out of routing supply lines
  • Small and thoughtful heat exchanger design supports full use of RAM slots
  • Refill port extends the product’s useful lifespan and promotes silent operation
  • Compatible with Intel® and AMDTM sockets
  • Convenient radiator mounting is compatible to most case designs

General

Model
SILENT LOOP | 360mm

Main Specification

Dimensions radiator, incl. fan (H x W x D), (mm)
397 x 124 x 55
Total weight (kg)
1,7
Socket compatibility
Intel®: LGA 775 / 1150 / 1151 / 1155 / 1156 / 1366 / 2011(-3) Square ILM / 2066
AMD™: AM2(+) / AM3(+) / AM4 / FM1 / FM2(+)
Maximum power capacity (W TDP)
450
Backplate Mounting
Fan model, number
3x Pure Wings 2 | 120mm PWM
Pump type
reverse-flow pump
Pump speed (rpm)
2,200
Pump connector
3-pin
Tube length
390
Bend-protection tubes
Refill port

Radiator Specification

Dimensions (H x W x D), (mm)
397 x 124 x 30
Radiator material / finish
copper / black spray painted
Base material / finish
copper / dark nickel plated
CPU contact surface
CNC machined
Surface treatment
mirror polished

General Fan Specifications

Fan dimensions (mm)
120 x 120 x 25
Noise level (dB(A)) @ 25 % / 50% /100% rpm
16.1 / 23.8 / 36.9
Speed @ 100% PWM (rpm)
2,000
Air flow @ 12V (cfm / m3/h)
65.51 / 111.3
Air pressure @ 12V (mm H2O)
2.23
Bearing type
Rifle
Motor technology
Rated voltage (V)
12
Input current (A)
0.3
Input power (W)
3.6
Connector
4-pin PWM
Cable length (mm)
450
Lifespan (h / 25°C)
80,000

Accessories

Thermal grease (g)
1
Backplate mounting set Intel & AMD
User manual languages
DE, EN, FR, ES, PL, RU

Service

Warranty (Years)
3
International hotline / free of charge
✓ / DE, FR

Logistics Data, RRP

Article number
BW004
Range
SILENT LOOP
EAN code
4260052185476
Meer informatie
EAN 4260052185476
Vendor ID BW004
Voorraad status End of life
Socket Socket 1150, Socket 1151, Socket 1155/1156, Socket 1366, Socket 2011, Socket 2011-v3, Socket 2066, Socket 775, Socket AM2/AM3, Socket AM3+, Socket AM4, Socket FM1, Socket FM2/FM2+
Aantal Heatpipes Geen heatpipes
Type koeling Waterkoeling
